Norton Winter Diamond Electroplated S-Series Micro Drill
Features and benefits
A modification of mounted points, these tools are specifically designed for drilling holes in the .007 Inch to .065 Inch diameter range
Perfect for drilling sapphire and high density alumina ceramics for hybrid micro-circuit substrates
S-Series - Recommended for adapting to ultrasonic drill heads
Exposed particles for aggressive cutting action
Part Specifications
Where to Buy|
Diameter
|
Grit Size
|
Stone Grit Size
|
Inventory Type
|
Shank Diameter
|
Overall Length
|
Part Number
|
|---|---|---|---|---|---|---|
| .016 In. | 200 Grit | 200/230 Grit | MTO | 1/8 In. | 1 In. | 66260395520 |
| .018 In. | 200 Grit | 200/230 Grit | Stock | 1/8 In. | 1 In. | 66260392841 |
| .020 In. | 200 Grit | 200/230 Grit | MTO | 1/8 In. | 1 In. | 66260395521 |
| .025 In. | 200 Grit | 200/230 Grit | MTO | 1/8 In. | 1 In. | 66260395522 |
| .030 In. | 150 Grit | 140/170 Grit | Stock | 1/8 In. | 1 In. | 66260395523 |
| .035 In. | 150 Grit | 140/170 Grit | MTO | 1/8 In. | 1 In. | 66260395524 |
| .040 In. | 150 Grit | 140/170 Grit | MTO | 1/8 In. | 1 In. | 66260395525 |
| .045 In. | 100 Grit | 100/120 Grit | MTO | 1/8 In. | 1 In. | 66260395526 |
| .050 In. | 100 Grit | 100/120 Grit | MTO | 1/8 In. | 1 In. | 66260395527 |
| .060 In. | 100 Grit | 100/120 Grit | MTO | 1/8 In. | 1 In. | 66260395528 |
| .065 In. | 100 Grit | 100/120 Grit | MTO | 1/8 In. | 1 In. | 66260395529 |
Product Uses
Applications
Materials
