Norton Winter Diamond Electroplated Series 6000 Mounted Point

Diamond Electroplated Mounted Points are precision engineered to meet the high demands of tool and die, ceramic and composite applications. We offer many stock products with varying shapes and grits that will maintain tight tolerances and provide superior form holding when used wet or dry.

Features and benefits

Use diamond mounted points for precise, small hole, jig and internal grinding of carbide, ceramics, sapphire, glass, and a variety of tough, super alloys

Mandrels are made of high-speed tool steel to withstand operating pressure

Single layer of abrasive offers an economical choice

Exposed particles for aggressive cutting action

Customise columns

Product SpecsDownload as CSV

Grit Size	Stone Grit Size	Inventory Type	Shank Diameter	Overall Length	Part Number
150 Grit	140/170 Grit	MTO	3/8 In.	3-3/4 In.	66260392693
80 Grit	80/100 Grit	MTO	3/8 In.	3-3/4 In.	66260392694
150 Grit	140/170 Grit	MTO	3/8 In.	3-3/4 In.	66260392697
80 Grit	80/100 Grit	MTO	3/8 In.	3-3/4 In.	66260392698
150 Grit	140/170 Grit	MTO	3/8 In.	3-3/4 In.	66260392701
80 Grit	80/100 Grit	Stock	3/8 In.	3-3/4 In.	66260392702
80 Grit	80/100 Grit	MTO	3/8 In.	3-3/4 In.	66260392706
150 Grit	140/170 Grit	MTO	3/8 In.	3-3/4 In.	66260392709
80 Grit	80/100 Grit	MTO	3/8 In.	3-3/4 In.	66260392710
150 Grit	140/170 Grit	MTO	3/8 In.	3-3/4 In.	66260392713
80 Grit	80/100 Grit	MTO	3/8 In.	3-3/4 In.	66260392714
150 Grit	140/170 Grit	MTO	3/8 In.	3-3/4 In.	66260392717
80 Grit	80/100 Grit	MTO	3/8 In.	3-3/4 In.	66260392718
150 Grit	140/170 Grit	MTO	3/8 In.	3-3/4 In.	66260392721
80 Grit	80/100 Grit	MTO	3/8 In.	3-3/4 In.	66260392722
150 Grit	140/170 Grit	Stock	3/8 In.	3-3/4 In.	66260392725
80 Grit	80/100 Grit	Stock	3/8 In.	3-3/4 In.	66260392726
