Norton SG 5SG Type 11 Toolroom Wheel
Features and benefits
Type 11 flaring cup wheels with high-performance proprietary ceramic alumina and friable aluminum oxide abrasive blend for cool superior cutting; 3 - 5X more life than aluminum oxide wheels; 2X rough stock removal vs conventional abrasives
High performance bond for versatility (for grinding high sped tool steels, hardened and soft steels, and aerospace alloys) and exceptional form holding
Self-sharpening abrasive minimizes burn and dressing, to maximize sharp edge on tools and dies for longer life in production
Outstanding choice for high productivity, low total per-part grinding cost on CNC cutting tool and tool and cutter machines
Part Specifications
Where to Buy|
Diameter
|
Arbor Hole
|
Thickness
|
Back Thickness
|
Rim Thickness
|
Grit Size
|
Sanding Grade
|
Inventory Type
|
Max Operating Speed
|
External Spec
|
Face Profile
|
Abrasive
|
Part Number
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5 in | 1-1/4 in | 1-3/4 in | 1/2 in | 1/4 in | 60 Grit | Medium | Stock | 4585 | 5SG60-LVS | Z Face | Ceramic Alumina | 66252830736 |
| 5 in | 1-1/4 in | 1-3/4 in | 1/2 in | 1/4 in | 46 Grit | Coarse | Stock | 4585 | 5SG46-KVS | Z Face | Ceramic Alumina | 66252803291 |
| 5 in | 1-1/4 in | 1-3/4 in | 1/2 in | 1/4 in | 60 Grit | Medium | Stock | 4585 | 5SG60-KVS | Z Face | Ceramic Alumina | 66252830737 |
| 4 in | 1-1/4 in | 1-1/2 in | 1/2 in | 1/4 in | 46 Grit | Coarse | Stock | 5730 | 5SG46-KVS | Z Face | Ceramic Alumina | 66243503342 |
| 4 in | 1-1/4 in | 1-1/2 in | 1/2 in | 1/4 in | 46 Grit | Coarse | Stock | 5730 | 5SG46-IVSP | Z Face | Ceramic Alumina | 66243530127 |
| 4 in | 1-1/4 in | 1-1/2 in | 1/2 in | 1/4 in | 60 Grit | Medium | Stock | 5730 | 5SG60-JVS | Z Face | Ceramic Alumina | 66243530415 |
| 4 in | 1-1/4 in | 1-1/2 in | 1/2 in | 1/4 in | 60 Grit | Medium | Stock | 5730 | 5SG60-LVS | Z Face | Ceramic Alumina | 66243530417 |
| 4 in | 1-1/4 in | 1-1/2 in | 1/2 in | 1/4 in | 80 Grit | Medium | Stock | 5730 | 5SG80-JVS | Z Face | Ceramic Alumina | 66243530419 |
| 4 in | 1-1/4 in | 1-1/2 in | 1/2 in | 1/4 in | 80 Grit | Medium | Stock | 5730 | 5SG80-KVS | Z Face | Ceramic Alumina | 66243530420 |
